Digital modules

3.16 Digital input module SM 321; DI 16 x AC 120/230 V; (6ES7321-1FH00-0AA0)

S7-300 Module data

Manual, 06/2017, A5E00105505-AJ

113

Technical specifications

Sensor selection data

Input voltage

• Rated value

• "1" signal

• "0" signal

• Frequency band

120/230 VAC

79 V to 264 V

0 V to 40 V

47 Hz to 63 Hz

Input current

• "1" signal

120 V, 60 Hz

230 V, 50 Hz

typ. 6.5 mA

typ. 16.0 mA

Input delay

• "0" to "1" transition

max. 25 ms

Input characteristics

to IEC 61131, type 1

Connection of 2-wire BEROs

• Permissible quiescent current

supported

max. 2 mA

Wiring the signal transducers

using a 20-pin front connector
