3.17 Digital input module SM 321; DI 8 x AC 120/230 V; (6ES7321-1FF01-0AA0)
S7-300 Module data
Manual, 06/2017, A5E00105505-AJ
115
SM 321; DI 8 x AC 120/230 V - Technical specifications
Technical specifications
Dimensions and weight
Dimensions W x H x D (mm) 40 x 125 x 117
Weight
ca. 240 g
Module-specific data
Supports isochronous mode
no
Number of inputs
8
Cable length
• unshielded
• shielded
max. 600 m
max. 1000 m
Voltages, currents, electrical potentials
Number of simultaneously controlled inputs
• horizontal mounting position
to 60 °C
8
• vertical mounting position
to 40 °C
8
Electrical isolation
• between channels and the backplane bus
yes
• between channels
in groups of
yes
2
Maximum potential difference
• between M
internal
and inputs
230 VAC
• between inputs of different groups
500 VAC
Isolation test voltage
4000 VDC
Current consumption
• from the backplane bus
max. 29 mA
Power loss of the module
typ. 4.9 W
Status, interrupts, diagnostics
Status display
green LED per channel
Interrupts
none
Diagnostic functions
none
