Digital modules

3.18 Digital input module SM 321; DI 8 x AC 120/230 V ISOL; (6ES7321-1FF10-0AA0)

S7-300 Module data

Manual, 06/2017, A5E00105505-AJ

119

Technical specifications

Sensor selection data

Input voltage

• Rated value

• "1" signal

• "0" signal

• Frequency band

120/230 VAC

79 V to 264 V

0 V to 40 V

47 Hz to 63 Hz

Input current

• "1" signal

120 V, 60 Hz

230 V, 50 Hz

typ. 7.5 mA

typ. 17.3 mA

Input delay

• "0" to "1" transition

max. 25 ms

Input characteristics

to IEC 61131, type 1

Connection of 2-wire BEROs

supported

• Permissible quiescent current

max. 2 mA

Wiring of the signal sensors

using a 40-pin front connector
