Digital modules
3.19 Digital output module SM 322; DO 64 x DC 24 V/0.3 A sourcing; (6ES7322-1BP00-0AA0)
S7-300 Module data
Manual, 06/2017, A5E00105505-AJ
125
GSD/GSDML files
The 64-channel I/O modules are supported by the ET 200M versions listed below. Download
the corresponding GSD/GSDML files from the following link: on the Internet
(
http://www.siemens.com/automation/service
).
● To search for PROFIBUS GSD files, type in the entry ID 113498.
● To search for PROFINET GSDML files, type in the entry ID: 25057900.
PROFIBUS
● IM 153-1, as of 6ES7153-1AA03-0XB0, E12 with GSD file SI01801D.*, version V 1.5
● IM 153-2, as of 6ES7153-2BA02-0XB0, E01 with GSD file SI04801E.*, version V 1.0
PROFINET
● IM 153-4 PN, as of 6ES7153-4AA00-0XB0 with GSDML file version V 2.1
● IM153-4 PN IO HF, as of 6ES7153-4BA00-0XB0 with GSDML file version V2.1
Using the module in S7-300 and ET 200M
If the station is configured with STEP 7, you can use the digital output module SM 322 with
all CPUs in the following table. Startup cannot be performed if no configuration is loaded.
C-CPUs (compact CPUs)
Order number
CPU 312C
6ES7312-5BD0x-0AB0
6ES7312-5BE03-0AB0
6ES7312-5BF04-0AB0
CPU 313C
6ES7313-5BE0x-0AB0
6ES7313-5BF03-0AB0
6ES7313-5BG04-0AB0
CPU 313C-2 DP
6ES7313-6CE0x-0AB0
6ES7313-6CF03-0AB0
6ES7313-6CG04-0AB0
CPU313C-2 PtP
6ES7313-6BE0x-0AB0
6ES7313-6BF03-0AB0
6ES7313-6BG04-0AB0
CPU 314C-2 DP
6ES7314-6CF0x-0AB0
6ES7314-6CG03-0AB0
6ES7314-6CH04-0AB0
CPU 314C-2 PtP
6ES7314-6BF0x--0AB0
6ES7314-6BG03--0AB0
6ES7314-6BH04-0AB0
CPU314C-2 PN/DP
6ES7314-6EH04-0AB0
