Digital modules
3.20 Digital output module SM 322; DO 64 x DC 24 V/0.3 A Sinking (6ES7322-1BP50-0AA0)
S7-300 Module data
132 Manual, 06/2017, A5E00105505-AJ
Control of a digital input
Switching frequency
• With resistive load
• With inductive load to IEC 947-5-1, DC 13
1
• With lamp load
Max. 100 Hz
Max. 0.5 Hz
Max. 10 Hz
Internal limiting of the inductive shutdown voltage to:
Short-circuit protection of the output
• Response threshold
Yes, electronic
1.7 A to 3.5 A typ.
Two 40-pin terminal blocks
1
For loads above 200 mA, a terminal diode is required for the inductive load
.
Recommended fuse
Groups of outputs must be protected by a 4 A/125 V fast-blow fuse (recommended: Littelfuse
235 004P 125 V 4 A). If the fuse is installed in a danger zone in accordance with the National
Electric Code (NEC), you must always use a suitable tool to remove it. Before removing or
replacing the fuse, you must determine whether or not you are dealing with a danger zone.
STEP 7 integration
64-channel I/O modules are integrated with the HSP 2019 V 1.0. The HSP forms part of
STEP 7 V 5.4 SP2 and can be installed from STEP 7 V 5.4 and higher.
GSD/GSDML files
The 64-channel I/O modules are supported by the ET 200M versions listed below. Download
the corresponding GSD/GSDML files from the following link: on the Internet
(
http://www.siemens.com/automation/service
).
● To search for PROFIBUS GSD files, type in the entry ID 113498.
● To search for PROFINET GSDML files, type in the entry ID: 25057900.
PROFIBUS
● IM 153-1, as of 6ES7153-1AA03-0XB0, E12 with GSD file SI01801D.*, version V 1.5
● IM 153-2, as of 6ES7153-2BA02-0XB0, E01 with GSD file SI04801E.*, version V 1.0
PROFINET
● IM 153-4 PN, as of 6ES7153-4AA00-0XB0 with GSDML file version V 2.1
● IM153-4 PN IO HF, as of 6ES7153-4BA00-0XB0 with GSDML file version V2.1
