Siemens SIMATIC User Manual

Digital modules
3.27 Digital output module SM 322; DO 16 x AC 120/230 V/1 A; (6ES7322-1FH00-0AA0)
S7-300 Module data
168 Manual, 06/2017, A5E00105505-AJ
SM 322; DO 16 x AC 120/230 V/1 A - Technical specifications
Technical specifications
Dimensions and weight
Dimensions W x H x D 40 x 125 x 117
Weight
ca. 275 g
Module-specific data
Supports isochronous mode
No
Number of outputs
16
Cable length
• unshielded
• shielded
max. 600 m
max. 1000 m
Voltages, currents, electrical potentials
Load voltage L1
All load voltages must be connected to the same phase
120/230 VAC
Total current of outputs (per group)
• horizontal mounting position
to 40 °C
to 60 °C
max. 4 A
max. 2 A
• vertical mounting position
to 40 °C
max. 2 A
Electrical isolation
• between channels and the backplane bus
yes
• between channels
in groups of
yes
8
Maximum potential difference
• between M
internal
and outputs
230 VAC
• between outputs of different groups
500 VAC
Isolation test voltage
4000 VDC
Current consumption
• from the backplane bus
• from load voltage L+ (no-load)
max. 200 mA
max. 2 mA
Power loss of the module
typ. 8.6 W
Status, interrupts, diagnostics
Status display
green LED per channel
Interrupts
• Diagnostic interrupt
no
Diagnostic functions
• Group error display
red LED (SF)
(fuse or no L1/N)
