Digital modules

3.28 Digital output module SM 322; DO 8 x DC 24 V/2 A; (6ES7322-1BF01-0AA0)

S7-300 Module data

Manual, 06/2017, A5E00105505-AJ

173

Technical specifications

Switching frequency

• with resistive load

max. 100 Hz

• with inductive load to IEC 947-5-1, DC 13

max. 0.5 Hz

• with lamp load

max. 10 Hz

Internal limiting of the inductive shutdown voltage to

typ. L + (-48 V)

Short-circuit protection of the output

yes, electronic

• Threshold

typ. 3 A

Wiring of the actuators using a 20-pin front connector
