Siemens SIMATIC User Manual

Digital modules
3.30 Digital output module SM 322; DO 8 x DC 48-125 V/1.5 A; (6ES7322-1CF00-0AA0)
S7-300 Module data
186 Manual, 06/2017, A5E00105505-AJ
Technical specifications
Actuator selection data
Output voltage
• "1" signal
min. L+ (-1.2 V)
Output current
• "1" signal
Rated value
Permitted range
1.5 A
10 mA to 1.5 A
• Permitted surge current
max. 3 A for a duration of 10 ms
• with "0" signal (residual current)
max. 0.5 mA
Output delay (resistive load)
• "0" to "1" transition
• "1" to "0" transition
max. 2 ms
max. 15 ms
Lamp load
max. 15 W at 48 V
max. 40 W at 125 V
Wiring two outputs in parallel
• for redundant load control
supported (only outputs of the same group)
• for performance increase
not supported
Control of a digital input
supported
Switching frequency
• with resistive load
• with inductive load
• with lamp load
max. 25 Hz
max. 0.5 Hz
max. 10 Hz
Internal limiting of the inductive shutdown voltage to
typ. M (-1V)
Short-circuit protection of the output
• Threshold
yes, electronic
3)
typ. 4.4 A
Replacement fuses
Fuse 6.3 A/250 V, fast-blow, 5 x 20 mm
• Schurter
• Wickman
SP0001.1012
194-1630-0
Fuse holder
• Wickman
653 0000 040
Wiring of the actuators
using a 20-pin front connector
1) Fuses on this module are only supplementary. External surge current protection (suitable
for tap circuits conforming to local regulations for electrical engineering) is required in the
supply lines of the load circuit.
2) Possible errors:
- no load voltage
- defective fuse
- output overload
3) If an overload condition is detected, the output is disabled for the duration of ca. 2.4 s.
