Digital modules
3.38 Digital IO module SM 323; DI 8/DO 8 x DC 24 V/0.5 A; (6ES7323-1BH01-0AA0)
S7-300 Module data
230 Manual, 06/2017, A5E00105505-AJ
Technical specifications
Actuator selection data
Output voltage
"1" signal
min. L + (- 0.8 V)
Output current
"1" signal
Rated value
Permitted range
0.5 A
5 mA to 0.6 A
"0" signal (residual current)
Max. 0.5 mA
Output delay (resistive load)
"0" to "1" transition
"1" to "0" transition
Max. 100 μs
Max. 500 μs
Load resistance range
48 Ω to 4 kΩ
Lamp load
Max. 5 W
Wiring two outputs in parallel
for redundant load control
supported (only outputs of the same group)
for performance increase
not supported
Control of a digital input
supported
Switching frequency
with resistive load
with inductive load to IEC 947-5-1, DC 13
with lamp load
max. 100 Hz
max. 0.5 Hz
max. 10 Hz
Internal limiting of the inductive shutdown voltage to
typ. L + (- 53 V)
Short circuit-proof output
yes, electronic
Threshold
typ. 1 A
Wiring of the actuators
using a 20-pin front connector
