Siemens SIMATIC User Manual

Digital modules
3.39 Programmable digital IO module SM 327; DI 8/DO 8 x DC 24 V/0.5 A (6ES7327-1BH00-0AB0)
S7-300 Module data
234 Manual, 06/2017, A5E00105505-AJ
Technical specifications
Actuator selection data
Output voltage
• "1" signal
min. L+ (-1.5 V)
Output current
• "1" signal
Rated value
Permitted range
0.5 A
5 mA to 0.6 A
• "0" signal (residual current)
Max. 0.5 mA
Output delay (resistive load)
• "0" to "1" transition
• "1" to "0" transition
max. 350 μs
max. 500 μs
Load resistance range
48 Ω to 4 kΩ
Lamp load
max. 5 W
Wiring two outputs in parallel
• for redundant load control
supported
• for performance increase
not supported
Control of a digital input
supported
Switching frequency
• with resistive load
• with inductive load to IEC 947-5-1, DC 13
• with lamp load
max. 100 Hz
max. 0.5 Hz
max. 10 Hz
Internal limiting of the inductive shutdown voltage to
typ. L + (-54 V)
Short circuit-proof output
yes, electronic
• Threshold
typ. 1 A
Wiring of the actuators
using a 20pin front connector
