Principles of analog value processing

4.6 Wiring and connecting thermocouples

S7-300 Module data

250 Manual, 06/2017, A5E00105505-AJ

Thermocouple structure

Thermocouples consist of a pair of thermal probes and all necessary installation and

connecting parts. The thermocouple pair consists of two wires made of different metals, or of

metal alloys soldered or welded together at their ends.

The different thermocouple types, for example, K, J or N, are derived from different material

compositions. The measuring principle of all thermocouples is the same, irrespective of their

type.

①

Measurement point

②

Thermocouple with positive and negative thermal elements

③

Terminal

④

Compensating line

⑤

Reference junction

⑥

Supply line

⑦

Thermal voltage acquisition point

Figure 4-13 Fig. 4-22 Structure of thermocouples
