Siemens SIMATIC User Manual

Analog modules
6.5 Analog input module SM 331; AI 8 x 14 Bit High Speed; isochrone; (6ES7331-7HF0x-0AB0)
S7-300 Module data
Manual, 06/2017, A5E00105505-AJ
335
Measuring range modules
You may have to change the position of the measuring range module to suit the
measurement type and range. See table
Setting measuring methods and ranges of analog
input channels
. The settings are also printed on the module. Mark the position of the
measuring range module on the front door (see figure).
Measurement types and measuring ranges
Table 6- 13 Measurement types and ranges
Selected type of measurement
Measuring range
(type of sensor)
Measuring range module settings
V: Voltage
± 1 V
A
± 5 V
1 V to 5 V
± 10 V
B
4DMU: Current (4-wire transducer) 0 mA to 20 mA
4 mA to 20 mA
± 20 mA
C
2DMU: Current (2-wire transducer)
4 mA to 20 mA
D
Channel groups
The channels of SM 331; AI 8 x 14 Bit High Speed are arranged in four groups of two
channels. You can assign parameters only to one channel group.
SM 331; AI 8 x 14 bits High Speed is equipped with one measuring range module per
channel group.
The table below shows the relevant configuration of channel groups. The channel group
number is required to program SFC parameters in the user program.
Table 6- 14 Assignment of SM 331; AI 8 x 14 bits High Speed channels to channel groups
Channels ...
... form one channel group each
Channel 0
Channel group 0
Channel 1
Channel 2
Channel group 1
Channel 3
Channel 4
Channel group 2
Channel 5
Channel 6
Channel group 3
Channel 7
