Siemens SIMATIC User Manual

Analog modules
6.7 Analog input module SM 331; AI 8 x 12 bit;(6ES7331-7KF02-0AB0)
S7-300 Module data
Manual, 06/2017, A5E00105505-AJ
365
Parameters
Table 6- 20 Overview of the parameters for SM 331; AI 8 x 12 Bit
Parameters
Range of values
Default
Parameter
type
Scope
Enable
• Diagnostics interrupt
• Process interrupt when
limit exceeded
yes/no
yes/no
no
no
dynamic
Module
Process interrupt trigger
• High limit
• Low limit
May be restricted by the measuring range
from 32511 to - 32512
from - 32512 to 32511
- dynamic Channel
Diagnostics
• Group diagnostics
• with line continuity check
yes/no
yes/no
no
no
static Channel
group
Measurement
• Measurement type
disabled
Voltage V
4DMU current (4-wire transducer)
2DMU current (2-wire transducer)
R-4L resistance (4-wire connection)
RTD-4L thermoresistor
(linear, 4-wire connection)
TC-I thermocouple
(internal comparison)
TC-E thermocouple
(external comparison)
TC-IL thermocouple
(internal comparison)
TC-EL thermocouple
(linear, external comparison)
V
dynamic
Channel or
channel
group
• Measuring range
See the table
Measurement types and rang-
es
± 10 V
• Noise suppression
400 Hz; 60 Hz; 50 Hz; 10 Hz 50 Hz
