6.9 Analog input module SM 331; AI 8 x RTD; (6ES7331-7PF01-0AB0)
S7-300 Module data
Manual, 06/2017, A5E00105505-AJ
383
Technical specifications
Technical specifications
Dimensions and weight
Dimensions W x H x D (mm) 40 x 125 x 117
Weight
approx. 272 g
Module-specific data
Configuration in RUN possible
Yes
Behavior of the non-configured inputs Provides the last valid process value before the
parameter assignment
Supports isochronous operation
No
Number of inputs
8
Cable length
• Shielded
max. 200 m
Voltages, currents, potentials
Supply voltage of the electronics L+
• Reverse polarity protection
24 V DC
Yes
Constant measurement current for resistance-type transmitter
max. 5 mA (pulsed)
Electrical isolation
• Between channels and backplane bus
• between channels and electronics power supply
• Between the channels
In groups of
Yes
Yes
Yes
2
Insulation tested with
500 V DC
Current consumption
• From backplane bus
• from supply voltage L+
max. 100 mA
max. 240 mA
Power loss of the module
typ. 4.6 W
Analog value formation
Measuring principle
Integrating
Mode
8-channel mode (hardware filter)
Integration/conversion time/resolution (per channel)
• Configurable
• Basic conversion time in ms
• Additional conversion time for resistance measurement in ms
• Additional conversion time for wire break monitoring in ms
• Resolution (including overrange)
• Interference voltage suppression at interference frequency f1 in
Hz
Yes
80
100*
0
16-bit (including sign)
400 / 60 / 50
Smoothing of the measured values None/Weak/Medium/Strong
Conversion time (per channel)
100 ms
Basic execution time of the module (all channels enabled)
200 ms
