Siemens SIMATIC User Manual

Analog modules
6.10 Analog input module SM 331; AI 8 x TC; (6ES7331-7PF11-0AB0)
S7-300 Module data
406 Manual, 06/2017, A5E00105505-AJ
Parameters
Range of values
Default
Parameter
type
Scope
Diagnostics
• Group diagnostics
• with line continuity check
yes/no
yes/no
no
no
static
Channel
group
Measurement
• Measurement type
disabled
TC-IL thermocouple
(linear, internal comparison)
TC-EL thermocouple
(linear, external comparison)
TC-L00C thermocouple
(linear, ref. temp. 0 °C)
TC-L50C thermocouple
(linear, ref. temp. 50 °C)
TC-IL
dynamic
Channel
group
• Measuring range
See table
Measurement types and
measuring ranges (Page 404)
Type K
• Reaction to open thermocouple
Overflow; underflow Overflow
• Temperature unit
Degrees Centigrade; degrees Fahr-
enheit
degrees Cen-
tigrade
dynamic Module
• Mode of operation
8-channel mode (hardware filter)
8-channel mode (software filter)
4-channel mode (hardware filter)
8 channels,
hardware filter
dynamic Module
• Noise suppression*
50/60/400 Hz; 400 Hz; 60 Hz; 50 Hz; 50/60/400 Hz dynamic
Channel
group
• Smoothing
none
weak
medium
strong
none dynamic Channel
group
*
50/60/400 Hz only programmable for 8-channel mode (hardware filter) and 4-channel mode (hardware filter);
50 Hz, 60 Hz or 400 Hz only programmable for 8-channel mode (software filter)
See also
Diagnostics messages of analog input modules (Page 296)
