Analog modules
6.12 Analog output module SM 332; AO 8 x 12 bit; (6ES7332-5HF00-0AB0)
S7-300 Module data
Manual, 06/2017, A5E00105505-AJ
445
Technical specifications
Technical specifications
Dimensions and weight
Dimensions W x H x D (mm) 40 x 125 x 117
Weight
ca. 272 g
Module-specific data
Supports parameter reassignment in RUN
Yes
Reaction of non-programmed outputs Return the output value which was valid before the
parameterization
Supports isochronous mode
no
Number of inputs
8
Cable length
• shielded
max. 200 m
Voltages, currents, electrical potentials
Rated load voltage L+
• Reverse polarity protection
24 V DC
yes
• Electrical isolation
• between channels and the backplane bus
• between channels and electronics power supply
• between channels
• between channels and load voltage L+
yes
yes
no
yes
Maximum potential difference
• between S- and M
ANA
(CMV)
3 V DC
Isolation test voltage
500 V DC
Current consumption
• from the backplane bus
• From supply voltage L+
max. 100 mA
max. 340 mA
Power loss of the module
typ. 6.0 W
Generation of analog values
Resolution, including sign
• ± 10 V; ± 20 mA; 4 mA to 20 mA; 1 V to 5 V
• 0 V to 10 V; 0 mA to 20 mA;
• Conversion time (per channel)
11 bits + sign
12 Bit max.
0.8 ms
Transient recovery time
• with resistive load
• with capacitive load
• with inductive load
0.2 ms
3.3 ms
0.5 ms (1 mH)
3.3 ms (10 mH)
