Siemens SIMATIC User Manual

Analog modules
6.17 Analog IO module SM 334; AI 4/AO 2 x 12 bit; (6ES7334-0KE00-0AB0)
S7-300 Module data
488 Manual, 06/2017, A5E00105505-AJ
Technical specifications
Interference frequency suppression, error limits for inputs
Interference frequency suppression at F = n (f1 ± 1 %) (f1 = interference frequency)
• Common mode interference (V
pp
< 1 V)
• Seriesmode interference (peak interference value < rated input
range)
> 38 dB
> 36 dB
Crosstalk between inputs > 88 dB
Operational limit (across entire temperature range, relative to the measurement range end value in the selected input
range)
• Voltage input
0 V to 10 V ± 0.7 %
• Resistance input
10 kΩ ± 3.5 %
• Temperature input
Pt 100 ± 1 %
Basic error limit (operational limit at 25 °C, relative to the measurement range end value in the selected input range)
• Voltage input
0 V to 10 V ±0.5 %
• Resistance input
10 kΩ ± 2.8 %
• Temperature input
Pt 100 ± 0.8 %
Temperature error (relative to input range)
± 0.01 %/K
Linearity error (relative to input range)
±0.05 %
Repeat accuracy (in settled state at 25 °C, relative to input range)
± 0.05 %
Interference frequency suppression, error limits of outputs
Crosstalk between outputs
> 88 dB
Operational limit (across entire temperature range, relative to measurement range end value in the selected output range)
• Voltage output
± 1.0 %
Basic error limit (operational limit at 25 °C, relative to the measurement range end value in the selected output range)
• Voltage output
± 0.85 %
Temperature error (relative to output range)
± 0.01 %/K
Linearity error (relative to output range)
± 0.01 %
Repeat accuracy (in transient state at 25 °C, relative to output range)
± 0.01 %
Output ripple; range 0 Hz to 50 kHz (relative to output range)
± 0.1 %
Status, interrupts, diagnostics
Interrupts
none
Diagnostic function
none
Encoder selection data
Input ranges (rated values) / input impedance
• Voltage
0 V to 10 V 100 kΩ
• Resistance
10 kΩ 10 MΩ
• Temperature
Pt 100 10 MΩ
Maximum voltage at voltage input (destruction limit) max. 20 V continuous; 75 V for max. duration of 1 s
(duty factor 1:20)
