7.4 Position decoder module SM 338; POS-INPUT; (6ES7338-4BC01-0AB0)

S7-300 Module data

514 Manual, 06/2017, A5E00105505-AJ

Technical data

Isochronous times for the module

In Standard Mode TCI

TCO

ToiMin

TDPMin

850 µs

620 µs

90 µs

1620 µs

In Fast Mode TCI

TCO

ToiMin

TDPMin

700 µs

0 µs

900 µs

Age of the encoder values determined by the transfer process and the processing

Restriction of the monoflop time of the absol

ute value encoder:

(1 / transmission rate) < monoflop of the absolute value encoder < 64 µs + 2 x (1 / tran

mission rate)
