Interface modules

8.2 Interface module IM 360; (6ES7360-3AA01-0AA0)

S7-300 Module data

Manual, 06/2017, A5E00105505-AJ

517

Technical data

The overview below shows the technical data of interface module IM 360.

Technical data

Dimensions and weight

Dimensions W x H x D (mm) 40 x 125 x 120

Weight

approx. 250 g

Module-specific data

Cable length

• Maximum length to next IM

10 m

Current consumption

• from the backplane bus

350 mA

Power loss

typ. 2 W

Status and error LEDs

yes
