Parameter sets of signal modules

A.7 Parameters of analog input module SM 331; AI 8 x RTD

S7-300 Module data

540 Manual, 06/2017, A5E00105505-AJ

Structure of data record 128

The diagram below shows the structure of data record 128 of SM 331; AI 8 x RTD.

Figure A-7 Data record 128 of SM 331; AI 8 x RTD
