Parameter sets of signal modules
A.9 Parameters of analog input module SM 331; AI 8 x 13 Bit
S7-300 Module data
558 Manual, 06/2017, A5E00105505-AJ
Temperature measurement
The table below lists the temperature measurement codes to be enterd at byte 0 of data
record 1 (see the previous figure.)
Table A- 21 Temperature measurement codes of the analog input module
Temperature unit for linearization
Code
degrees Celsius
2#0000 0000
Degrees Fahrenheit 2#0000 1000
Kelvin
2#0001 0000
Interference frequency suppression
The table below contains the frequency codes to be entered at byte 1 of data record 1 (see
the previous figure.) Make allowances for the resultant integration time at each module!
Table A- 22 Interference frequency suppression codes of the analog input module
Interference frequency suppression
Integration time
Code
60 Hz 50 ms 2#01
50 Hz
60 ms
2#10
Measurement types and measuring ranges
The table below contains all the measurement types and measuring ranges of the analog
input module, including their codes. Enter these codes at bytes 2 to 13 in data record 1 (refer
to the previous figure.)
Note
The front connector of the analog input module must be wired in accordance with the
measuring range!
