Parameter sets of signal modules
A.13 Parameters of analog output module SM 332; AO 8 x 12 Bit
S7-300 Module data
Manual, 06/2017, A5E00105505-AJ
579
Output type and output range
The table lists the output types/ranges of SM 332; AO 8 x 12 Bit, including their codes. Enter
these codes at bytes 2 to 9 in data record 1 (refer to the previous figure.)
Table A- 33 Output range codes of analog output module SM 332; AO 8 x 12 Bit
Output type
Code
Output range
Code
Disabled
2#0000
Disabled
2#0000
Voltage 2#0001 1 V to 5 V
0 V to 10 V
± 10 V
2#0111
2#1000
2#1001
Current 2#0010 0 mA to 20 mA
4 mA to 20 mA
± 20 mA
2#0010
2#0011
2#0100
