Spare parts and accessories for S7-300 modules
S7-300 Module data
Manual, 06/2017, A5E00105505-AJ
617
Front connector for 2 ribbon cable connections
• screw terminal technology
• Spring clamp technology
6ES7921-3AB00-0AA0
6ES7921-3AA00-0AA0
Front connector for 4 ribbon cable connections
• Spring clamp technology
6ES7921-3AA20-0AA0
Round-sheath ribbon cable (16-pole)
• Unshielded 30 m
• Unshielded 60 m
• Shielded 30 m
• Shielded 60 m
6ES7923-0CD00-0AA0
6ES7923-0CG00-0AA0
6ES7923-0CD00-0BA0
6ES7923-0CG00-0BA0
Connectors, 16-pin, set of 8 (insulation displacement terminals)
Shield connection element
Shield terminal element for
• 2 cables, each with a shield diameter of 2 to 6 mm
• 1 cable with a shield diameter of 3 to 8 mm
• 1 cable with a shield diameter of 4 to 13 mm
6ES7390-5AB00-0AA0
6ES7390-5BA00-0AA0
6ES7390-5CA00-0AA0
Measuring range module for analog modules
Fuse set for digital output modules
- 6ES7322-1FF01-0AA0
- 6ES7322-1FH00-0AA0
- 6AG1322-1FF01-2AA0
(contains 10 fuses and 2 fuse holders)
6ES7973-1HD00-0AA0
Fuse set for digital output module
• 6ES7322-1CF00-0AA0 (contains 10 fuses)
6ES7973-1GC00-0AA0
Connecting cable for IM 360 and IM 361, or IM 361 and IM 361
• 1 m
• 2.5 m
• 5 m
• 10 m
6ES7368-3BB01-0AA0
6ES7368-3BC51-0AA0
6ES7368-3BF01-0AA0
6ES7368-3CB01-0AA0
Connecting cable between the 64-channel modules:
SM 321, 6ES7321-1BP00-0AA0 sinking/sourcing,
SM 322, 6ES7322-1BP00-0AA0 sourcing,
SM 322, 6ES7322-1BP50-0AA0 sinking
and 40-pin terminal block (screw terminal, spring clamp technology)
• 1.0 m
• 2.5 m
• 5.0 m
6ES7392-4BB00-0AA0 (2 units)
6ES7392-4BC50-0AA0 (2 units)
6ES7392-4BF00-0AA0 (2 units)
