Safety-relevant symbols

G.2 Safety-related symbols for devices with Ex protection

S7-300 Module data

Manual, 06/2017, A5E00105505-AJ

625

Symbol

Meaning

For Zone 2 potentially explosive atmospheres, be aware that the device may only

be used when it is installed in an enclosure with a degree of protection ≥ IP54.

For Zone 22 potentially explosive atmospheres, be aware that the device may

only be used when it is installed in an enclosure with a degree of protection ≥

IP6x.
