Digital modules

3.7 Digital input module SM 321; DI 32 x DC 24 V; (6ES7321-1BL00-0AA0)

S7-300 Module data

72 Manual, 06/2017, A5E00105505-AJ

Technical specifications

Current consumption

• From the backplane bus

Max. 15 mA

Power loss of the module Typ. 6.5 W

Status, interrupts, diagnostics

Status display Green LED per channel

Interrupts

None

Diagnostic functions

None

Encoder selection data

Input voltage

• Rated value

• "1" signal

• "0" signal

24 V DC

13 to 30 V

- 30 to + 5 V

Input current

• "1" signal

Typ. 7 mA

Input delay

• "0" to "1" transition

• "1" to "0" transition

1.2 ms to 4.8 ms

Input characteristics

to IEC 61131, type 1

Connection of 2-wire BEROs

• Permissible quiescent current

Supported

Max. 1.5 mA

Connection of the signal transmitters

Using a 40-pin front connector
