Digital modules

3.8 Digital output module SM 321; DI 32 x AC 120 V; (6ES7321-1EL00-0AA0)

S7-300 Module data

Manual, 06/2017, A5E00105505-AJ

Technical specifications

Current consumption

• from the backplane bus

max. 16 mA

Power loss of the module typ. 4 W

Status, interrupts, diagnostics

Status display green LED per channel

Interrupts

none

Diagnostic functions

none

Transducer selection data

Input voltage

• Rated value

• "1" signal

• "0" signal

• Frequency band

120 VAC

74 V to 132 V

0 V to 20 V

47 Hz to 63 Hz

Input current

• "1" signal

typ. 21 mA

Input delay

• "0" to "1" transition

• "1" to "0" transition

max. 15 ms

max. 25 ms

Input characteristics

to IEC 61131, type 2

Connection of 2-wire BEROs

• Permissible quiescent current

supported

max. 4 mA

Wiring the signal transducers

using a 40pin front connector
