Procedure
To relubricate the rolling bearings, proceed as follows:
1. Clean the grease nipples at the drive end and non-drive end.
2. Press-in the specied grease and amount of grease according to the data stamped on the
lubrication plate.
– Please observe the information on the rating and lubricant plates.
– Regreasing should be carried out when the motor is running (max. 3600 rpm).
The bearing temperature can rise signicantly at rst, and then drops to the normal value
again when the excess grease is displaced out of the bearing.
WARNING
Rotor can fall out
If the machine is in a vertical position, the rotor can fall out while work is being performed on
the locating bearing. This can result in death, serious injury or material damage.
Support or relieve the rotor when carrying out work with the machine in a vertical position.
9.2.9 Cleaning
Cleaning the grease ducts and spent grease chambers
The spent grease collects outside each bearing in the spent grease chamber of the outer bearing
cap. When replacing bearings, remove the spent grease.
Dismantle the bearing cartridges to replace the grease in the lubrication duct.
Cleaning the cooling air ducts
Regularly clean the cooling air ducts through which the ambient air ows.
The frequency of the cleaning intervals depends on the local degree of fouling.
Damage to the machine when cleaning with compressed air or water jets
• Do not direct compressed air or water jets in the direction of the shaft outlet or machine
openings.
• Avoid direct impact of compressed air and water jets on sealing elements of the machine.
Note
Please note the safety instructions for cleaning.
Maintenance
9.2Inspection and maintenance
1MB..1/2/3/4 - shaft heights 63 ... 355
Operating Instructions, 11/2023, A5E52779900A 123
