4.11 Rotational speed limit values
Danger as a result of resonance within certain speed ranges
At over-critical speeds, machines encounter resonance within certain speed ranges. Such
vibrations can reach impermissibly high levels. This can result in death, serious injury or material
damage.
• The controller must ensure that those speed ranges are blocked when the converter is in
operation. Please comply with the data on the blocked speed ranges specied in the electrical
data.
• The blocked speed ranges must be run through rapidly.
Machine damage due to excessively high speeds
Excessive rotational speed can lead to serious damage to the machine. This can result in death,
serious injury or material damage.
• Avoid operation above the permissible speed by using the appropriate control function.
• Comply with the speeds stamped on the rating plate and in the electrical data.
4.12 System-inherent frequencies
Excessively high vibration levels and system resonances can damage the machine set.
• Congure and match the system consisting of the foundation and machine set in such a way
that no system resonances can arise and result in the permissible vibration levels being
exceeded.
• Do not exceed the vibration values according to DINISO10816-3.
4.13 Electromagnetic compatibility
Note
If the torque levels are very unequal (e.g. when a reciprocating compressor is being driven), a
non-sinusoidal machine current will be induced whose harmonics can have an impermissible
eect on the supply system and cause impermissible interference emissions as a result.
Preparing for use
4.13Electromagnetic compatibility
1MB..1/2/3/4 - shaft heights 63 ... 355
54 Operating Instructions, 11/2023, A5E52779900A
