• The machine temperature class specied on the rating plate must be equal to or greater than
the temperature class of any combustible gases that may develop.
• Select optional mounted equipment according to the requirements of Directive 2014/34/EU,
IECEx scheme or in accordance with the appropriate country regulations.
5.3.3 Machines with type of construction IM B15, IM B9, IM V8 and IM V9
Types of construction without bearings on the drive side
These machines do not have their own bearing system for the machine shaft at the drive end
(DE). The machine shaft is accepted by the (hollow) shaft or coupling of the system or driven
machine.
• Using the centering edge, the machine is aligned with respect to enclosures, anges or
driven machines.
• Note that the temperature of the motor and motor shaft increases during operation. The
thermal expansion of the machine shaft must be compensated by the customer by applying
suitable measures.
Use the spring washers provided to locate the NDE bearing without any play.
NOTICE
Damage to the motor
Material damage can occur if the following notes are not carefully observed:
• The IM B3 bearing shield with integrated distance ring mounted at the drive end (DE) is only
used transport lock. A warning label is attached to this bearing shield.
• The spacer ring is not a roller bearing.
• Remove the bearing shield and the spacer ring.
• Remove the transport lock before commissioning.
5.3.4 Foot mounting
Note
Only authorized retrot partners must be employed to relocate the bolted-on mounting feet at
the machine enclosure.
After attaching the mounting feet, you must note the following in order to avoid stressing
and deforming the machine.
• Ensure that the foot mounting surfaces are aligned in one plane and are parallel to the
machine shaft.
• Post-machine the foot mounting surfaces or use thin shims, for example.
Assembly
5.3Mounting and installed the machine
1MB..1/2/3/4 - shaft heights 63 ... 355
68 Operating Instructions, 11/2023, A5E52779900A
