10.10 Standardized parts
Table 10-2 Purchase standard parts according to dimensions, material and surface properties through normal commercial
channels.
No Standard Picture No Standard Picture
3.02
6.02
7.12
DIN 471 
5.17

EN ISO 4014
6.12 DIN 472
4.04 DIN 580 1.49
4.11
4.39
5.65
5.89
7.49
7.86
EN ISO 4017
DIN 582
6.75 EN ISO 4026
1.60
6.10
DIN 625 1.30
1.45
4.11
5.19
5.46
5.47
5.49
6.29
7.88
7.91
7.94
EN ISO 4762
7.85
7.87
DIN 6796
3.38 DIN 6885 4.19 EN ISO 7045
4.12
5.55
EN ISO 4032 4.05
7.48

EN ISO 7089
5.51 EN ISO 4035
Spare parts
10.10Standardized parts
1MB..1/2/3/4 - shaft heights 63 ... 355
Operating Instructions, 11/2023, A5E52779900A 143
