6.1.5 Cable glands
Cable glands with (sheet metal) nuts (EN 50262)
①
②
Nut
O ring
Cable glands with reductions and (sheet metal) nuts (EN 50262)
①
②
Nut
O ring
6.1.5.1 Mounting position of sheet metal nuts in screw-type connections
②
③
O ring
Mounting position of metal-sheet
nuts
Electrical connection
6.1Connecting the machine
1MB..1/2/3/4 - shaft heights 63 ... 355
84 Operating Instructions, 11/2023, A5E52779900A
