Table 3-8 For applications in Zone 22 - IEC/EN/BS/GOST 60079-10-2, GB/T3836.35
II 3D Ex tc IIIA T... °C Dc BVS 14 ATEX E 081 X,
EPS 18 ATEX 1 202 X,
PTB 12 ATEX 3016
II 3D Ex tc IIIC T... °C Dc
II 3D Ex tc IIIB T... °C Dc BVS 14 ATEX E 081 X, EPS 18 ATEX 1 202 X,
FTZU 13 ATEX 0040, FTZU 13 ATEX 0055,
FTZU 15 ATEX 0084, PTB 12 ATEX 3016
Ex tc IIIA T... °C Dc IECEx EPS 18.0104X, IECEx PTB 17.0009
Ex tc IIIC T... °C Dc
Ex tc IIIB T... °C Dc IECEx BVS 14.0052X, IECEx EPS 18.0104X,
IECEx FTZU 13.0029, …0031,
IECEx FTZU 15.0034, IECEx PTB 17.0009
II 3D Ex tc IIIA T... °C Dc EPS 21 UKEX 1 255 X, ...303 X, …304
II 3D Ex tc IIIB T... °C Dc
II 3D Ex tc IIIC T... °C Dc EPS 21 UKEX 1 255 X, …256, …257, …258, ...303 X, …304
Ex tc IIIB T... °C Dc X EAЭC RU C-DE.AA87.B.00156/19,
EAЭC RU C-DE.AЖ58.B.02301/22
Ex tcIIIA T... °CDc 2020312301002066 … 068,
2020312301002073 … 076,
2020312301002087 … 089
Ex tcIIIB T... °CDc
Ex tcIIIC T... °CDc
Note
If the certicate number ends with an "X", then strictly comply with the information in
Chapter Certicate with special conditions (Page22).
3.3.11 Terminal box
As an option, additional connecting terminals are available in the terminal box for monitoring
equipment. For larger machines, an additional terminal box can be optionally mounted. You can
see the number of available terminals in the circuit diagrams.
It is possible to turn the top side of a machine terminal box 4 x 90 degrees (if screwed on).
3.3.12 Paint nish
Paint nish
The machine is painted according to the instructions in your order.
Description
3.3Installation
1MB..1/2/3/4 - shaft heights 63 ... 355
38 Operating Instructions, 11/2023, A5E52779900A
