Converter operation (VSD) rating plate











3.3 Installation
Machine design
The regulations and standards used as the basis to design and test this machine are stamped on
the rating plate.
The machine design basically complies with the subsequent standards. Please refer to the EU
Declaration of Conformity for the versions of the harmonized standards referenced.
3.3.1 Regulations
Table 3-1 Applicable general regulations
Feature Standard EAC GB BS
Dimensioning and operating behavior EN/IEC60034-1 GOSTIEC60034-1 GB755 IEC60034-1
Procedure for determining the losses and
the e󹪟ciency of rotating electrical ma‐
chines and inspections
EN/IEC60034-2-1
EN/IEC60034-2-2
EN/IEC60034-2-3
GOSTIEC60034-2-1
GOSTIEC60034-2-2
GOSTIEC60034-2-3
GB/T1032 BSEN60034-2-1
BSEN60034-2-2
BS EN IEC 60034-2-3
Degree of protection EN/IEC60034-5 GOSTIEC60034-5 GB/T4942.1 BSENIEC60034-5
Cooling EN/IEC60034-6 GOSTRIEC60034-6 GB/T1993 BSEN60034-6
Type of construction EN/IEC60034-7 GOSTRIEC60034-7 GB/T997 BSEN60034-7
Terminal designations and direction of ro‐
tation
EN/IEC60034-8 GOST26772 GB/T1971 BSEN60034-8
Noise emission EN/IEC60034-9 GOSTIEC60034-9 GB10069.3 BSEN60034-9
Integrated thermal protection EN/IEC60034-11 GOST27888 GB/T13002 BSEN60034-11
Starting characteristics of rotating electri‐
cal machines
EN/IEC60034-12 GOSTIEC60034-12 GB/T21210 BSEN60034-12
Description
3.3Installation
1MB..1/2/3/4 - shaft heights 63 ... 355
28 Operating Instructions, 11/2023, A5E52779900A
