5.5 Installing the machine
5.5.1 Preconditions for smooth, vibration-free operation
Preconditions for smooth, vibration-free operation:
• Stable foundation design
• Precise alignment of the machine
• Correct balancing of parts to be tted to the shaft end.
• Vibration values in compliance with ISO10816‑3
5.5.2 Aligning the machine to the driven machine and mounting
5.5.2.1 Type of construction without ange
If the motor is not tted with a ange, align the motor to suit the driven machine.
For types of construction without ange (e.g. IM B3), use suitable covers to ensure that no
small parts can fall down between the transmission element and the bearing shield on the
drive side.
5.5.2.2 Horizontal types of construction with mounting feet
1. Refer to any instructions for aligning the driven machine and those of the coupling
manufacturer.
2. Align the machines with coupling output to the driven machine in such a manner that the
center lines of the shafts are parallel with no oset. This ensures that no additional forces
aect their bearings during operation.
3. For the vertical positioning (x→0) place thin shims under the machine feet. The number of
shims should be kept as low as possible, i.e. stack as few as possible. This also prevents the
machine being subjected to any stress/distortion. If available, use the existing tapped holes
for the forcing-o bolts to somewhat raise the machine.
4. When positioning the machine, ensure that a uniform axial gap (y→0) is maintained around
the coupling.
5. Fix the machine to the foundation. The choice of xing elements depends on the foundation
and is the plant operator's responsibility.
Note
Machine expansion
When aligning, make allowance for the thermal expansion of the machine when the
temperature increases.
Assembly
5.5Installing the machine
1MB..1/2/3/4 - shaft heights 63 ... 355
Operating Instructions, 11/2023, A5E52779900A 71
