Page #327 background imageLoading...
Page #327 background image
Signal Cause Remedy
Complete information on the messages is available in the List Manual.
1042: Current or voltage plausibility error.
Increase the ramp-up and ramp-down time (p1120/p1121).
Check whether the current and speed control settings are correct
(torque-forming, field-forming current andactual speed value must
not fluctuate).
Reduce the dynamic response of the setpoint.
Increase the minimum current (p9588).
Maintain an adequate wait time before switching on the motor.
Switching on the motor when SLS is active (Page 266)
Switching on the motor when SSM is active (Page 278)
Switching on the motor when SDI is active (Page 285)
1043: Too many acceleration processes.
Increase the value for "Actual value sensing encoderless
acceleration limit" (p9589).
Increase the ramp-up and ramp-down time (p1120/p1121).
Check whether the current and speed control settings are correct
(torque-generating, field-generating current and speed actual
value must not fluctuate).
Reduce the dynamic response of the setpoint.
1044: Actual current value plausibility error.
6000 … 6166: The significance of the message values is described in
the safety fault F01611 with the fault value r0949.
C01712
(alarm)
1)
Defect when processing F-IO
1. Check the F-DI wiring.
2. Check the setting of the safety functions.
3. Perform an acceptance test.
C01714
(alarm)
1)
Safely limited speed exceeded
1. Check the speed setpoint received from the higher-level control.
2. Check the SLS limits.
C01716
(fault)
Tolerance for safe direction of mo‐
tion exceeded
Check the tolerance setting for the SDI function.
C01770
(fault)
Discrepancy error of the fail-safe
digital inputs.
Check the F-DI wiring.
A01772 Test stop for fail-safe digital output
running
The alarm automatically disappears after successfully ending or can‐
celing (error) the forced checking procedure (test stop).
F01773 Test stop for fail-safe digital output
error
1. Check the wiring of the fail-safe digital output.
2. Start the forced checking procedure.
A01774 Test stop for fail-safe digital output
required
The time to carry out the forced checking procedure (test stop) has
expired (p10003).
Start the forced checking procedure of the fail-safe output.
A01788 Automatic test stop waits for STO
to be deselected via the motion
monitoring functions
The inverter was not able to carry out the automatic test stop (forced
checking procedure) after switching on the power supply voltage. Pos‐
sible causes:
STO for the extended functions is selected.
A safety message is active, which resulted in STO.
Operation
6.14 List of alarms and faults
Safety Integrated - SINAMICS G110M, G120, G120C, G120D and SIMATIC ET 200pro FC-2
Function Manual, 01/2017, FW V4.7 SP6, A5E34261271B AD 327
