13.Switch on the inverter supply voltage again.
The inverter reports the faults F01641, F01650, F01680 and F30680. Ignore these faults,
as they will be automatically acknowledged by the following steps.
14.Set p0010 to 95.
15.Set p9761 to the safety password.
16.Set p9701 to AC hex.
17.Set p0010 to 0.
18.Back up the settings so they are not lost when the power fails: Menu "SAVE RAM TO ROM".
19.Switch off the inverter power supply.
20.Wait until all LEDs on the inverter are dark.
21.Switch on the inverter supply voltage again.
22.Perform a reduced acceptance test.
Reduced acceptance after a component has been replaced and a firmware change
(Page 366)
You have replaced the inverter and transferred the safety function settings from the operator
panel to the new inverter.
Corrective maintenance
7.6 Replacing the SIMATIC ET 200pro FC-2 inverter
Safety Integrated - SINAMICS G110M, G120, G120C, G120D and SIMATIC ET 200pro FC-2
364 Function Manual, 01/2017, FW V4.7 SP6, A5E34261271B AD
