Siemens SINAMICS G120C Function Manual

Components in separate control cabinets
:LULQJLQVWHHOFRQGXLW
&RQWUROFDELQHW
&RQWUROFDELQHW
/RJLF
/RJLF
0
6WDUW
5.$$
444/0
7,1,1,1 ,17,1,1,1,1
5.$$
/044
7,1,17,1,1
9'&
0
672B$
672B%
9
9
9
9
6,1$0,&6*
3RZHU0RGXOH
30
303
Figure 4-38 Wiring inverters and modular safety systems in separate control cabinets
When installed in separate control cabinets, route the cables between the modular safety
system and the inverter, protected against cross and short-circuits.
If you wish to use the fail-safe digital outputs of the 3RK3 central module for a two-channel
signal transfer, then you must adapt the discrepancy monitoring of the inverter to the different
switching times of electronic output and relay contact.
Installing
4.4 Controlling via a fail-safe digital input
Safety Integrated - SINAMICS G110M, G120, G120C, G120D and SIMATIC ET 200pro FC-2
90 Function Manual, 01/2017, FW V4.7 SP6, A5E34261271B AD

Siemens SINAMICS G120C Specifications

General

Communication Interfaces	PROFINET, PROFIBUS, USS, Modbus RTU
Protection Class	IP20
Ambient Temperature	-10°C to +50°C
Storage Temperature	-40°C to +70°C
Power Range	0.55 kW to 132 kW
Voltage Range	380 V to 480 V
Output Voltage	0 V to Supply Voltage
Frequency Range	0 Hz to rated output frequency
Control Modes	Vector control with encoder
Protection	Overload, overvoltage, undervoltage, short circuit, ground fault
Relative Humidity	5% to 95%, non-condensing
Altitude	Up to 2000 m without derating
