Operation
6.7 Control via the operator panel
Drive converter cabinet units
226 Operating Instructions, 07/07, A5E00288214A
Vector object
Table 6-18 List of signals for the operation screen - vector object
Signal Parameters Short name Unit Scaling (100 %=...) See
table below
Factory setting (entry no.)
Speed setpoint upstream of ramp-function
generator
(1) r1114 NSETP 1/min p2000
Output frequency (2) r0024 F_OUT Hz Reference frequency
Power smoothed (3) r0032 PACTV kW r2004
DC link voltage smoothed (4) r0026 U_DC V p2001
Actual speed smoothed (5) r0021 N_ACT 1/min p2000
Absolute actual current smoothed (6) r0027 I_IST A p2002
Motor temperature (7) r0035
1)
T_MOT °C Reference temperature
Converter temperature (8) r0037 T_LT °C Reference temperature
Actual torque smoothed (9) r0031 M_ACT Nm p2003
Converter output voltage smoothed (10) r0025 C_OUT V p2001
For diagnostic purposes
Speed setpoint smoothed r0020 NSETP 1/min p2000
Control factor smoothed r0028 AUSST % Reference modulation
depth
Field-producing current component r0029 IDACT A p2002
Torque-producing current component r0030 IQACT A p2002
Converter overload
Degree of thermal overload
r0036 LTI2T % 100 % = Shutdown
Speed actual value motor encoder r0061 N_ACT 1/min p2000
Speed setpoint after filter r0062 NSETP 1/min p2000
Actual speed smoothed r0063 N_ACT 1/min p2000
Control deviation r0064 NDIFF 1/min p2000
Slip frequency r0065 FSCHL Hz Reference frequency
Output frequency r0066 F_OUT Hz Reference frequency
Output voltage r0072 UACT V p2001
Control factor r0074 AUSST % Reference modulation
depth
Torque-generating actual current r0078 IQACT A p2002
Actual torque value r0080 M_ACT Nm p2003
For further diagnostic purposes
Fixed speed setpoint effective r1024 1/min p2000
Active motorized potentiometer setpoint r1050 1/min p2000
Resulting speed setpoint r1119 NSETP 1/min p2000
Speed controller output r1508 NREGY Nm p2003
I component of speed controller r1482 NREGI Nm p2003
PROFIBUS setpoint r2050 PBSOL 1/min p2000
1)
If a temperature sensor has not been installed, a value of –200°C is displayed.
