SINUMERIK 802D sl Operating and Service Training Manual Page 8
C83
C83
Section 3
Tool types for milling/drilling
When you have selected this tool type, you must remember to use G17 as
your workplane.
When you set the tool o
ffset
you must also rem
ember to set the correct
Axis to Length 1 and Length 2 in t
he
Geometry colum
n.
This is your
Z axis offset
This is your
X axis offset
Shown below is a typical program for drilling on the End Face of your
turned component using G17
Default plane acti-
vated at end of cycle
Selected
plane
