SINUMERIK 802D sl Operating and Service Training Manual Page 6

C19

Section 3

Restoring All data from Compact flash card

Select HMI archive

and with COPY soft-

key prepare for paste

operation to

CNC

Select HMI directory

and press “p

aste”

softkey
