Notes
SINUMERIK 802D sl Operating and Service Training Manual Page 7
C19
C19
Section 3
Restoring All data from Compact flash card
Confirm the dialog box with the OK softkey, the HMI archive will now be
read into the
controller.
During this r
eading in process the controller will reboot once, the process
will take app
roximately 1 minute to complete.
This procedure should be repeated f
or the NC/PLC archive, the CNC will
reboot more times and the process t
akes approximately 4 minutes to com-
plete. The NC_PLC arch
ive should be copied to the NC PLC directory and
not the HMI.
Upon completion of this
process the machine should be functional again.
Note: The HMI archive should be rea
d in first because the specific PLC
alarms are in the NC/PL
C archive.
