Notes
SINUMERIK 802D sl Operating and Service Training Manual Page 17
C99
C99
Section 4
Drilling cycles
G00 G90 G94 G40 G71 G17
T4
M6
G95 S1500 F0.25 M03 M08
G00 G54 X-60.0 Y0.0 Z50.0
CYCLE71(
50.00000, 0.50000, 2.00000, 0.00000, -100.00000, -
100.00000, 200.00000, 200.00000, 0.00000,
2.50000, 40.00000, 4.00000,
0.10000, 50
0.00000, 12, 4.00000)
G00 G40 Z1
00.0
T5
M6
G95 S2500 F0.25 M03 M08
G00 G54 X0.0 Y0.0 Z50.0
POCKET4(
50.00000, 0.00000, 2.00000, -15.00000, 40.00000, 0.00000,
0.00000, 2.5
0000, 0.10000, 0.05000, 500.00000, 250.00000, 3, 12,
6.00000, , ,
10.00000, 1.00000)
G00 G40 Z2
00.0
T1
M6
G95 S1500 F0.25 M03 M08
G00 G54 X6
0.0 Y0.0 Z50.0
MCALL
CYCLE82( 50.00000, 0.00000, 2.00000, -5.25000, 0.00000,
0.50000)
HOLES2( 0.00000, 0.00
000, 60.00000, 0.00000, 90.00000, 4)
MCALL
T2
M6
G95 S800 F
0.2 M03 M08
G00 G54 X6
0.0 Y0.0 Z50.0
MCALL
CYCLE81( 50.00000, 0.00000, 2.00000, -30.00000, 0.00000)
HOLES2( 0.00000, 0.00
000, 60.00000, 0.00000, 90.00000, 4)
MCALL
T3
M6
G95 S800 F
2.0 M03 M08
G00 G54 X6
0.0 Y0.0 Z50.0
MCALL
CYCLE84( 0.00000, 0.00000, 2.00000, -18.00000, 0.00000,
0.10000, 3,
1.00000, , ,800.00000, 800.00000)
HOLES2( 0.00000, 0.00
000, 60.00000, 0.00000, 90.00000, 4)
MCALL
G00 G40 X0
.0 Y150.0 Z200.
M30
If you now p
ut both parts of the pr
ograms together, then you would have a
program that would FACE, machine POCKET, CENTER
DRILL, DRILL
and TAP yo
ur component.
