11
Alarms and Messages 08.02
11.2 Alarms with ManualTurn
11
© Siemens AG, 2002. All rights reserved
11-182 SINUMERIK 840D/810D Operator's Guide ManualTurn (BAM) – 08.02 Edition
111 902
Start with valid reference point only
Explanation The axes have no valid reference point.
Reaction Alarm display
Remedy Reference all axes
111 904
4th axis not configured, that is, no powered tool possible
Explanation MD9643 CTM_ENABLE_DRIVEN_TOOL was activated, without a 4th
axis being known to the system.
Reaction Alarm display
Remedy Create a 4th axis. To do this, change the following machine data:
• Channel-specific
20070 $MC_AXCONF_MACHAX_USED [3]=4
• Axis-specific for the 4th axis
30300 $MA_IS_ROT_AX=1
30310 $MA_ROT_IS_MODULO=1
30320 $MA_DISPLAY_IS_ MODULO=1
30350 $MA_SIMU_AX_VDI_OUTPUT=1
35000 $MA_SPIND_ASSIGN_TO_MACHAX=2
112 999
Faulty graphics data
Exit graphic and start again
Explanation More data have been generated than the operator interface can read.
Reaction Alarm display
Stop graphic
Remedy Deselect graphic and select again.
n
