11
08.02 Alarms and Messages
11.2 Alarms with ManualTurn
11
© Siemens AG, 2002. All rights reserved
SINUMERIK 840D/810D Operator's Guide ManualTurn (BAM) – 08.02 Edition 11-181
MD9617: $MM_CTM_TEACH_HANDW_FEED_P_REV
MD9620: $MM_CTM_CYCLE_SAFETY_CLEARANCE
MD9633: $MM_CTM_INC_DEC_FEED_PER_MIN
MD9634: $MM_CTM_INC_DEC_FEED_PER_ROT
MD9637: $MM_CTM_MAX_INP_FEED_P_MIN
MD9638: $MM_CTM_MAX_INP_FEED_P_ROT
MD9639: $MM_CTM_MAX_TOOL_WEAR
MD9648: $MM_CTM_ROUGH_O_RELEASE_DIST
MD9649: $MM_CTM_ROUGH_I_RELEASE_DIST
MD10240: $MN_SCALING_SYSTEM_IS_METRIC
MD20150 [12]: $MC_GCODE_RESET_VALUES
• Tool data:
Length X, length Z, radius
wear lengths X and Z, vconst
• Zero offsets:
Position in X, Z
Note This alarm can only occur with hardware faults.
111 430
Program not loaded. Error when converting old cycles into G
code. No NC memory.
Explanation In previous ManualTurn versions, STRAIGHT, CONICAL and
CIRCULAR steps were saved as cycles. They are now saved as
G-code (CONICAL, CIRCLE without angle programming). When a
sequence is loaded, a check is performed to see if any old cycles were
used. If any old cycles are found, the chain is converted and saved
again in the NC. In the event of an error (memory full), this alarm is
output.
Reaction Sequence is not loaded.
Remedy To create a new sequence, there must be sufficient free memory to
store the original sequence and the backup copy.
111 900
It is only possible to start in the basic display
Explanation A G-code program can only be started from the basic display for a
mode (except for MANUAL).
Reaction Alarm display
Remedy Change to the basic display for a mode (except for MANUAL).
Start single-step with NC start.
111 901
Contour is contained in the current program
Processing not enabled
Explanation There is a contour in the current EasyStep sequence that must not be
altered.
Reaction Alarm display
Remedy Stop execution. Reload EasyStep sequence and edit as required.
