11
Alarms and Messages 08.02
11.2 Alarms with ManualTurn
11
© Siemens AG, 2002. All rights reserved
11-180 SINUMERIK 840D/810D Operator's Guide ManualTurn (BAM) – 08.02 Edition
111 400
Unknown PLC error
Explanation An error signal unknown to the user interface has been output by the
PLC.
Reaction Alarm display
NC start disable
Remedy Activate POWER ON, inform Siemens.
111 410
Tool %1 was created
Explanation As ManualTurn starts, it check that all standard tools are present. If
any are not, the missing tools are generated automatically.
If more than one tool is created, the tools are output in a combined
message.
Meaning: Example:
%1 Number of tool which was created, 5
%1 First and last tool which were created, 5...16
Reaction None
Remedy None
111 411
%1 tool(s) could not be created
Explanation As ManualTurn starts, it check that all standard tools are present. If
any are not, the missing tools are generated automatically.
The specified number of tools could not be created in this case.
Reaction Alarm display
NC start disable
Remedy Increase machine data 18082 $MM_NUM_TOOL by the specified
amount.
111 420
Error at inch/metric switchover!
Check all data!
Explanation Data switchover was not fully terminated for inch/metric switchover.
Reaction Alarm display
NC start disable
Remedy Check the following data:
• Display machine data:
MD9004: $MM_DISPLAY_RESOLUTION
MD9600: $MM_CTM_SIMULATION_DEF_X
MD9601: $MM_CTM_SIMULATION_DEF_Y
MD9602: $MM_CTM_SIMULATION_DEF_VIS_AREA
MD9603: $MM_CTM_SIMULATION_MAX_X
MD9604: $MM_CTM_SIMULATION_MAX_Z
MD9605: $MM_CTM_SIMULATION_MAX_VIS_AREA
MD9616: $MM_CTM_TEACH_HANDW_FEED_P_MIN
