Turning Simple Contours 08.02
4.2 Turnin
g
with
p
ath dimension in
p
ut
4
© Siemens AG, 2002. All rights reserved
4-72 SINUMERIK 840D/810D Operator's Guide ManualTurn (BAM) – 08.02 Edition
Example 1
D = 60°
E = 90°
180°
270°
90°
D
E
Example 2
α = 60°
ß = 150°
α
αα
α
β
ββ
β
180°
270°
0°
90°
180°
90°
0°
270°
Example 3
X+
Z+
45
°
R30
Angle
Select the soft key labeled "Angle".
Enter circle data and confirm each entry with the "Input" key
e.g. D 180°
E 45°
R 30.
Select alternative circle data by means of the "Alternat." soft key.
