15
Tables 04.00
15.2 List of s
stem variables
15
ï›™
Siemens AG 2000. All rights reserved
15-520
SINUMERIK 840D/840Di/810D/FM-NC Programming Guide Advanced (PGA) – 04.00 Edition
Identifier Type Description: System variable/value range/index Part pro Sync O S
$TC_DPCSi
REAL The type can be defined in the machine data. The default is REAL
$TC_DPCS
i
[t,d]
With active 'Flat D number management' function, the syntax is as
follows:
$TC_DPCS
i
[d]
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 5
.
2
$TC_DPCS10
REAL The type can be defined in the machine data. The default is REAL
$TC_DPCS10[t,d]
With active 'Flat D number management' function, the syntax is as
follows:
$TC_DPCS10[d]
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 5
.
2
$TC_SCP13
REAL Offset for $TC_DP3: $TC_SCP13[t,d] analogous to $TC_DP12[t,d]
With active 'Flat D number management' function, the syntax is as
follows:
$TC_SCP13[d]
t: T number 1–32000
d: Cutting edge number/D number 1– 32000
RW 5
$TC_SCP14
REAL Offset for $TC_DP4: $TC_SCP14[t,d] analogous to $TC_DP13[t,d]
With active 'Flat D number management' function, the syntax is as
follows:
$TC_SCP14[d]
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 5
...
... ...
$TC_SCP21
REAL Offset for $TC_DP11: $TC_SCP21[t,d] analogous to $TC_DP20[t,d]
With active 'Flat D number management' function, the syntax is as
follows:
$TC_SCP21[d]
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 5
$TC_SCP23
REAL Offset for $TC_DP3: $TC_SCP23[t,d] analogous to $TC_DP12[t,d]
With active 'Flat D number management' function, the syntax is as
follows:
$TC_SCP23[d]
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 5
$TC_SCP24
REAL Offset for $TC_DP4: $TC_SCP24[t,d] analogous to $TC_DP13[t,d]
With active 'Flat D number management' function, the syntax is as
follows:
$TC_SCP24[d]
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 5
