Siemens SINUMERIK 840D Programming Guide

15
Tables 04.00
15.2 List of s
y
stem variables
15

Siemens AG 2000. All rights reserved
15-522
SINUMERIK 840D/840Di/810D/FM-NC Programming Guide Advanced (PGA) – 04.00 Edition
Identifier Type Description: System variable/value range/index Part pro Sync O S
$TC_SCP53
REAL Offset for $TC_DP3: $TC_SCP53[t,d] analogous to $TC_DP12[t,d]
With active 'Flat D number management' function, the syntax is as
follows:
$TC_SCP53[d]
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 5
$TC_SCP54
REAL Offset for $TC_DP4: $TC_SCP54[t,d] analogous to $TC_DP13[t,d]
With active 'Flat D number management' function, the syntax is as
follows:
$TC_SCP54[d]
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 5
...
...
$TC_SCP61
REAL Offset for $TC_DP11: $TC_SCP61[t,d] analogous to $TC_DP20[t,d]
With active 'Flat D number management' function, the syntax is as
follows:
$TC_SCP61[d]
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 5
$TC_SCP63
REAL Offset for $TC_DP3: $TC_SCP63[t,d] analogous to $TC_DP12[t,d]
With active 'Flat D number management' function, the syntax is as
follows:
$TC_SCP63[d]
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 5
$TC_SCP64
REAL Offset for $TC_DP4: $TC_SCP64[t,d] analogous to $TC_DP13[t,d]
With active 'Flat D number management' function, the syntax is as
follows:
$TC_SCP64[d]
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 5
...
...
$TC_SCP71
REAL Offset for $TC_DP11: $TC_SCP71[t,d] analogous to $TC_DP20[t,d]
With active 'Flat D number management' function, the syntax is as
follows:
$TC_SCP71[d]
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 5
