04.00 Tables
15.2 List of s
y
stem variables
15

Siemens AG 2000. All rights reserved
SINUMERIK 840D/840Di/810D/FM-NC Programming Guide Advanced (PGA) – 04.00 Edition
15-523
Identifier Type Description: System variable/value range/index Part pro Sync O S
$TC_ECP13
REAL Offset for $TC_DP3: $TC_ECP13[t,d] analogous to $TC_DP12[t,d]
With active 'Flat D number management' function, the syntax is as
follows:
$TC_ECP13[d]
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 5
$TC_ECP14
REAL Offset for $TC_DP4: $TC_ECP14[t,d] analogous to $TC_DP13[t,d]
With active 'Flat D number management' function, the syntax is as
follows:
$TC_ECP14[d]
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 5
...
...
$TC_ECP21
REAL Offset for $TC_DP11: $TC_ECP21[t,d] analogous to $TC_DP20[t,d]
With active 'Flat D number management' function, the syntax is as
follows:
$TC_ECP21[d]
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 5
$TC_ECP23
REAL Offset for $TC_DP3: $TC_ECP23[t,d] analogous to $TC_DP12[t,d]
With active 'Flat D number management' function, the syntax is as
follows:
$TC_ECP23[d]
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 5
$TC_ECP24
REAL Offset for $TC_DP4: $TC_ECP24[t,d] analogous to $TC_DP13[t,d]
With active 'Flat D number management' function, the syntax is as
follows:
$TC_ECP24[d]
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 5
...
...
$TC_ECP31
REAL Offset for $TC_DP11: $TC_ECP31[t,d] analogous to $TC_DP20[t,d]
With active 'Flat D number management' function, the syntax is as
follows:
$TC_ECP31[d]
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 5
