Identifier Type Description: System variable/value range/index Part pro Sync O S
$TC_ECP33
REAL Offset for $TC_DP3: $TC_ECP33[t,d] analogous to $TC_DP12[t,d]
With active 'Flat D number management' function, the syntax is as
follows:
$TC_ECP33[d]
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 5
$TC_ECP34
REAL Offset for $TC_DP4: $TC_ECP34[t,d] analogous to $TC_DP13[t,d]
With active 'Flat D number management' function, the syntax is as
follows:
$TC_ECP34[d]
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 5
...
...
$TC_ECP41
REAL Offset for $TC_DP11: $TC_ECP41[t,d] analogous to $TC_DP20[t,d]
With active 'Flat D number management' function, the syntax is as
follows:
$TC_ECP41[d]
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 5
$TC_ECP43
REAL Offset for $TC_DP3: $TC_ECP43[t,d] analogous to $TC_DP12[t,d]
With active 'Flat D number management' function, the syntax is as
follows:
$TC_ECP43[d]
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 5
$TC_ECP44
REAL Offset for $TC_DP4: $TC_ECP44[t,d] analogous to $TC_DP13[t,d]
With active 'Flat D number management' function, the syntax is as
follows:
$TC_ECP44[d]
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 5
...
...
$TC_ECP51
REAL Offset for $TC_DP11: $TC_ECP51[t,d] analogous to $TC_DP20[t,d]
With active 'Flat D number management' function, the syntax is as
follows:
$TC_ECP51[d]
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 5
$TC_ECP53
REAL Offset for $TC_DP3: $TC_ECP53[t,d] analogous to $TC_DP12[t,d]
With active 'Flat D number management' function, the syntax is as
follows:
$TC_ECP53[d]
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 5
